Ercolina TB80 Top Bender

Name: Ercolina TB80 Top Bender
Brand: Ercolina
SKU: TB80
Price: 37800.0 USD
Availability: InStock

SKU: TB80 by Ercolina

$37,800.00 - $37,800.00

$37,800.00

$37,800.00 - $37,800.00

$37,800.00

Call for our Best Deal (855) 605-4599

Quantity

Ercolina TB80 Top Bender

3" OD x .120" wall round tube - plus 2-1/2" x .125" wall square tube.
2-1/2" Schedule 40 pipe - rated on A53 pipe; heavy wall and high-tensile material reduce capacity.
2 x OD to 16.5" centerline radius - bends to 180 degrees with per-bend springback and speed compensation.
7" touch screen, 30 bends per program - unlimited program storage via USB, inch or metric.
Electromechanical drive, no hydraulics - variable 1.5 to 3 RPM, quiet operation, right or left hand bending.
Mandrel-ready - with Ercolina's optional mandrel accessory.
Quick-change 40, 50 and 80mm drive tooling - swing-away counterbend die vise with electronic position monitoring.
220V or 480V 3-phase, 980 lb - 20" x 34" x 47"; 1-year limited warranty.

Ships via LTL / Truck Freight

Due to the size and weight of this product, this item ships on a Pallet via LTL / Truck Freight.

We provide real-time pricing for LTL freight including the various options listed below - rates can be seen on the checkout page.

LTL Freight has a number of options, depending on your ability to unload the goods.

The basic service offers delivery by truck where the receiver must unload the goods themself - usually a loading bay and / or a forklift is required to do this.

Lift Gate (L) means your goods will be delivered in a truck that is equipped with a tailgate loader / lift-gate. In this situation, the driver will move your goods from the truck to the lift-gate and lower the goods to ground level. You are then responsible for moving the goods from the lift-gate.

Inside delivery (I) is where the driver will move the goods from the truck to ground level and then move the into your premises.

All residential deliveries must include the lift-gate service and delivery is usually made curb-side meaning you are responsible for moving the goods into your premises / workshop / garage.

If you have any questions about LTL delivery or need to make alternate arrangements, please contact us on (855) 605 4599 and we are happy to assist.

You can view our Shipping Policy Here

Product Downloads

Download Ercolina TB80 Top Bender Spec Sheet

Download Ercolina Top Bender Single Bend Programming Guide

Download Ercolina Top Bender Multiple Bend Programming Guide

Ercolina TB80 Top Bender: 3" Tube and 2-1/2" Schedule 40 Pipe

The Ercolina TB80 is an electromechanical rotary draw tube bender for round tube up to 3" OD x .120" wall, 2-1/2" Schedule 40 pipe and 2-1/2" x .125" wall square tube. Centerline radius runs from 2 x OD up to 16.5", and it bends to 180 degrees with springback and speed compensation set independently for each bend. There are no hydraulic components, so it runs quietly and there is no fluid to service.

Programming is on a 7" touch screen in inch or metric, with up to 30 bends per program and unlimited program storage via USB. Bend angle and bend speed are shown on the display, the counterbend die vise position is monitored electronically for repeatability, and a foot pedal runs the bend and return. The swing-away counterbending die vise makes loading and unloading long or heavy material easier, and the steel gear case bends right or left hand.

Tooling is quick-change, with 40mm, 50mm and 80mm drive diameters. Ercolina offers a 5-piece pipe kit (PIPEKIT6, 1" to 2-1/2" pipe) and a large radius tube kit (TUBEKIT5, 1" to 2" tube), and individual center formers and counterbend dies are in Ercolina tube and pipe dies. The TB80 is also mandrel-ready with Ercolina's optional mandrel accessory, and CML USA confirms it has the capacity for 2" Schedule 40 stainless pipe.

The machine is 20" x 34" x 47", weighs 980 lb and runs on 220V or 480V 3-phase; choose the voltage when you order. It ships LTL freight and carries Ercolina's 1-year limited warranty. Capacities are rated on A53 pipe; heavy wall and high-tensile material reduce capacity. If you need 4" tube, step up to the TB100. See all Ercolina tube benders or the full range of tube and pipe benders at Shape The Metal.
